Video duct inspection robot
INSPECTION BEFORE AND AFTER THE AIR DUCT CLEANING WORK, A MANDATORY TASK
An inspection is mandatory both before and after the air duct cleaning process. For this reason, Visiobot is the perfect tool to accompany this work.
Its stainless steel structure makes it resistant to impacts and falls.
Thanks to its compact and resistant design, it is easy to transport.
In addition, its long battery life allows it to be used anywhere, even in areas without access to electricity.
- The most advanced technology in visualization and recording of images inside air ducts.
- It has a high-resolution Easy Touch touch screen, allows capturing HD videos and images, and adding text, date and time to the recordings.
- Possibility of instant replay of recordings.
- Intuitive and easy to use interface, with large internal memory.
TECHNICAL DATA SHEET
| Power supply | 220V / 50Hz // 110V / 60Hz |
| Power | 75 W max. |
| Power supply | Electric and battery |
| Battery | Li-ion 6600mAh (97,68Wh) / 14,4V |
| Control panel | Membrane keyboard and joystick |
| Display System | 11.6″ / 256GB Full HD 1080p 60Hz display |
| Dimensions | 470 x 357 x 176 mm 18.5 x 14.1 x 6.9 inches |
| Weight | 8.5 kg // 18.74 lb |
| Cable length tractor connection | 20 m // 49 ft |
| Material of structure | ABS and HDPE |
Duct video inspection robot.
Commercial and industrial buildings, offices, government agencies, hospitals and schools, and public and private companies have the need to clean their ducts on a regular basis.
The National Air Duct Cleaners Association (NADCA ) sets the industry standard for HVAC cleaning, and when done correctly, HVAC cleaning can have many benefits.
Tecai is a member of NADCA, so when you buy our equipment, you should expect a high level of performance from it.
